When objects get very hot (or, by extension, very energetic), they give off X-rays. Some of the most intriguing objects in the Universe- black holes, exploded stars, clusters of galaxies-reveal much about themselves through X-rays.

An X-ray machine can't act like Chandra and photograph an X-ray source. Chandra, however, can act like the camera in an X-ray machine and reveal information about what's between the source and the camera.

More Information

X-rays can't be seen with the human eye, and don't have any "color." Images taken by telescopes that observe at the "invisible" wavelengths are sometimes called false color images. That's because the colors used to make them are not real but are chosen to bring out important details. The color choice is typically used as a type of code in which the colors can be associated with the intensity or brightness of the radiation from different regions of the image, or with the energy of the emission.

More Information

Another reason why a telescope like the Chandra X-ray Observatory is so remarkably successful is that X-ray astronomy is very technically challenging. One of the biggest problems is that X-rays that strike a 'regular' mirror head on will just be absorbed. In order to focus X-rays onto a detector, the mirrors have to be shaped like barrels so that the X-rays strike them at grazing angles, just like pebbles skipping across a pond.

More Information

X-ray photons entering the telescope are reflected at grazing angles and focused onto an electronic detector to make an image of a cosmic source.

More Information

The Chandra X-ray Observatory captures X-ray images and measures spectra of many high-energy cosmic phenomena. Unlike Hubble, its sister "Great Observatory," Chandra has a highly elliptical orbit that takes it 1/3 of the way to the Moon. This orbit allows Chandra to observe continuously for many hours at a time, but makes it unreachable by the Space Shuttle, which was used to launch it back in 1999. (High Def version available by request)

More Information

The X-ray data obtained by Chandra is typically stored on board for about 8 hours worth at a time. About three times a day, Chandra communicates with the Deep Space Network, sending its newly acquired data back to Earth while receiving new instructions from the ground.

The Deep Space Network consists of three dishes in Australia, Spain, and California. It is the primary way (think of a cosmic phone line) that Earth maintains contact with missions through the Solar System.

More Information

This Google Earth video shows the three locations of the Deep Space Network (Spain, Australia, and the US). Next you'll zip to the Jet Propulsion Laboratory (JPL) in California and then you'll complete the trip at the Chandra Operations Control Center and the Harvard-Smithsonian Center for Astrophysics in Massachusetts, US.

More Information

The data transmitted via the Deep Space Network doesn't come in the form of polished images or spectra. Rather, it appears as a series of positions and times. The tables of information can then be translated into an image, for example, by plotting the position on a grid. Each additional photon for a location makes that point appear brighter, thus representing a stronger X-ray source.
