Data Sonification: A New Cosmic Triad of Sound

  • A new installment of 'sonified' objects from space has been released.

  • Data sonification is the process of turning information collected by telescopes into sounds.

  • This new trio of images includes the Bullet Cluster, the Crab Nebula, and SN 1987A.

  • The resulting sounds are based on X-ray, optical and/or infrared data and how they vary across the image.

A new trio of examples of 'data sonification' from NASA missions provides a new method to enjoy an arrangement of cosmic objects. Data sonification translates information collected by various NASA missions — such as the Chandra X-ray Observatory, Hubble Space Telescope, and Spitzer Space Telescope — into sounds.

This image of the Bullet Cluster (officially known as 1E 0657-56) provided the first direct proof of dark matter, the mysterious unseen substance that makes up the vast majority of matter in the Universe. X-rays from Chandra (pink) show where the hot gas in two merging galaxy clusters has been wrenched away from dark matter, seen through a process known as "gravitational lensing" in data from Hubble (blue) and ground-based telescopes. In converting this into sound, the data pan left to right, and each layer of data was limited to a specific frequency range. Data showing dark matter are represented by the lowest frequencies, while X-rays are assigned to the highest frequencies. The galaxies in the image revealed by Hubble data, many of which are in the cluster, are in mid-range frequencies. Then, within each layer, the pitch is set to increase from the bottom of the image to the top so that objects towards the top produce higher tones.

The Crab Nebula has been studied by people since it first appeared in Earth's sky in 1054 A.D. Modern telescopes have captured its enduring engine powered by a quickly spinning neutron star that formed when a massive star collapsed. The combination of rapid rotation and a strong magnetic field generates jets of matter and anti-matter flowing away from its poles, and winds outward from its equator. For the translation of these data into sound, which also pans left to right, each wavelength of light has been paired with a different family of instruments. X-rays from Chandra (blue and white) are brass, optical light data from Hubble (purple) are strings, and infrared data from Spitzer (pink) can be heard in the woodwinds. In each case, light received towards the top of the image is played as higher pitched notes and brighter light is played louder.

On February 24, 1987, observers in the southern hemisphere saw a new object in the Large Magellanic Cloud, a small satellite galaxy to the Milky Way. This was one of the brightest supernova explosions in centuries and soon became known as Supernova 1987A (SN 87A). This time lapse shows a series of Chandra (blue) and Hubble (orange and red) observations taken between 1999 and 2013. This shows a dense ring of gas, which was ejected by the star before it went supernova, begins to glow brighter as the supernova shockwave passes through. As the focus sweeps around the image, the data are converted into the sound of a crystal singing bowl, with brighter light being heard as higher and louder notes. The optical data are converted to a higher range of notes than the X-ray data so both wavelengths of light can be heard simultaneously.

The data sonification project is led by the Chandra X-ray Center (CXC) as part of the NASA's Universe of Learning (UoL) program. NASA's Science Activation program strives to enable NASA science experts and to incorporate NASA science content into the learning environment effectively and efficiently for learners of all ages. The collaboration was driven by visualization scientist Kimberly Arcand (CXC), astrophysicist Matt Russo and musician Andrew Santaguida (both of the SYSTEMS Sound project.)

NASA's Marshall Space Flight Center manages the Chandra program. The Smithsonian Astrophysical Observatory's Chandra X-ray Center controls science from Cambridge Massachusetts and flight operations from Burlington, Massachusetts. NASA's Universe of Learning materials are based upon work supported by NASA under cooperative agreement award number NNX16AC65A to the Space Telescope Science Institute, working in partnership with Caltech/IPAC, Center for Astrophysics | Harvard & Smithsonian, Jet Propulsion Laboratory, and Sonoma State University.



Fast Facts for Bullet Cluster:
Credit  X-ray: NASA/CXC/SAO; Optical: NASA/STScI, Magellan/U.Arizona; Lensing Map: NASA/STScI, ESO WFI, Magellan/U.Arizona; Sonification: NASA/CXC/SAO/K.Arcand, SYSTEM Sounds (M. Russo, A. Santaguida)
Release Date  November 30, 2020
About the Sound
  • Synthesized sound consisting of combinations of sine waves controlled by data in the image.

  • Compact sources produce short, pure tones, extended sources such as dark matter/x-ray gas produce noisy roaring sounds.

  • Optical layer has a harp sound for each galaxy.
  • Scale  Image is about 7.5 arcmin (7.4 light years) across
    Category  Groups & Clusters of Galaxies
    Coordinates (J2000)  RA 06h 58m 37.9s | Dec -55° 57´ 00.00"
    Constellation  Carina
    Observation Date  2004: Aug 10, 11, 14, 15, 17, 19, 24, 25
    Observation Time  140 hours (5 days 20 hours)
    Obs. ID  5355-58, 5361, 4984-86
    Instrument  ACIS
    Color Code  Energy (X-ray: pink; Optical: white/orange; Lensing Map: blue)
    Optical
    X-ray
    Distance Estimate  About 3.8 billion light years
    distance arrow


    Fast Facts for Crab Nebula:
    Credit  X-ray: NASA/CXC/SAO; Optical: NASA/STScI; Infrared: NASA-JPL-Caltech; Sonification: NASA/CXC/SAO/K.Arcand, SYSTEM Sounds (M. Russo, A. Santaguida)
    Release Date  November 30, 2020
    About the Sound
  • X-rays from Chandra are brass.

  • Optical light data from Hubble are strings.

  • Infrared data from Spitzer are woodwinds.
  • Scale  Image is about 5 arcmin (10 light years) across
    Category  Supernovas & Supernova Remnants, Neutron Stars/X-ray Binaries
    Coordinates (J2000)  RA 05h 34m 32s | Dec +22° 0.0´ 52.00"
    Constellation  Taurus
    Observation Date  48 pointings between March 2000 and Nov 2013
    Observation Time  25 hours 28 min (1 day 1 hour 28 min)
    Obs. ID  769-773, 1994-2001, 4607, 13139, 13146, 13147, 13150-13154, 13204-13210, 13750-13752, 13754-13757, 14416, 14458, 14678-14682, 14685, 16245, 16257, 16357, 16358
    Instrument  ACIS
    Color Code  X-ray: blue, Optical: purple, Infrared: pink
    IR
    Optical
    X-ray
    Distance Estimate  About 6,500 light years
    distance arrow


    Fast Facts for Supernova 1987A:
    Credit  X-ray: NASA/CXC/SAO; Optical: NASA/STScI; Sonification: NASA/CXC/SAO/K.Arcand, SYSTEM Sounds (M. Russo, A. Santaguida)
    Release Date  November 30, 2020
    About the Sound
  • As the focus sweeps around the image, the data are converted into the sound of a crystal singing bowl, with brighter light being heard as higher and louder notes.

  • The optical data are converted to a higher range of notes than the X-ray data so both wavelengths of light can be heard simultaneously.
  • Scale  Image is about 20 arcsec (14 light years) across
    Category  Supernovas & Supernova Remnants
    Coordinates (J2000)  RA 05h 35m 28.30s | Dec -69° 16´ 11.10"
    Constellation  Dorado
    Observation Date  4 pointings between Jan 2008 and Jan 2009; Timelapse: 33 pointings between Oct 1999 and Sept 2015
    Observation Time  22 hours 13 minutes
    Obs. ID  9142, 9143, 9806, 10130, 122, 1044, 1387, 1967, 2831, 2832, 3829, 3830, 4614, 4615, 5579, 5580, 6668, 6669, 7636, 7637, 9142-9144, 10130, 10222, 10855, 11090, 12539, 12540, 13131, 13735, 14697, 14698, 15809, 15810, 16756, 16757
    Instrument  ACIS
    Color Code  X-ray: blue, Optical: red
    Optical
    X-ray
    Distance Estimate  About 168,000 light years
    distance arrow
