Tycho's Supernova Remnant: NASA'S Chandra Finds New Evidence on Origin of Supernovas
tycho2
Tycho's Supernova Remnant
Tycho's Supernova Remnant
Tycho's Supernova Remnant
Visual Description:

  • An arc of emission just found in the Tycho supernova remnant provides evidence for what triggered the original explosion.

  • Astronomers think that a shock wave created the arc when a white dwarf exploded and blew material off the surface of a nearby companion star.

  • Tycho belongs to a category of supernovas that are used to measure the expansion of the Universe.

This new image of Tycho's supernova remnant, dubbed Tycho for short, contains striking new evidence for what triggered the original supernova explosion, as seen from Earth in 1572. Tycho was formed by a Type Ia supernova, a category of stellar explosion used in measuring astronomical distances because of their reliable brightness.

Low and medium energy X-rays in red and green show expanding debris from the supernova explosion. High energy X-rays in blue reveal the blast wave, a shell of extremely energetic electrons. Also shown in the lower left region of Tycho is a blue arc of X-ray emission. Several lines of evidence support the conclusion that this arc is due to a shock wave created when a white dwarf exploded and blew material off the surface of a nearby companion star (see accompanying illustration below). Previously, studies with optical telescopes have revealed a star within the remnant that is moving much more quickly than its neighbors, hinting that it could be the companion to the supernova that was given a kick by the explosion.

Tycho

Other details of the arc support the idea that it was blasted away from the companion star. For example, the X-ray emission of the remnant shows an apparent "shadow" next to the arc, consistent with the blocking of debris from the explosion by the expanding cone of material stripped from the companion. This shadow is most obvious in very high energy X-rays showing iron debris.

These pieces of evidence support a popular scenario for triggering a Type Ia supernova, where a white dwarf pulls material from a "normal," or Sun-like, companion star until a thermonuclear explosion occurs. In the other main competing theory, a merger of two white dwarfs occurs, and in this case, no companion star or evidence for material blasted off a companion, should exist. Both scenarios may actually occur under different conditions, but the latest Chandra result from Tycho supports the former one.

The shape of the arc is different from any other feature seen in the remnant. Other features in the interior of the remnant include recently announced stripes, which have a different shape and are thought to be features in the outer blast wave caused by cosmic ray acceleration.

Visual Description:

This is a Chandra X-ray image that features Tycho's supernova remnant. The main colors in the image are blue, purple and golden-green, with a circular shape dominating the image on a background of black. The structure of the supernova remnant can be seen clearly in the X-ray image, revealing intricate details with knots and finger-like shapes seemingly coming out of the nebula, and some towards the viewer. There is a bright blue circle around the perimeter from high energy X-rays, which comes from a shell of extremely energetic electrons in the explosion’s blast wave. Low and medium energy X-rays in red and green show expanding debris from the supernova explosion. Also shown in the lower left region of Tycho, around 8 o’clock, is a striking blue arc of X-ray emission. Several lines of evidence support the conclusion that this arc is due to a shock wave created when a white dwarf exploded and blew material off the surface of a nearby companion star.



Fast Facts for Tycho's Supernova Remnant:
Credit  NASA/CXC/Chinese Academy of Sciences/F. Lu et al
Release Date  April 26, 2011
Scale  Image is 10 arcmin across (about 38 light years)
Category  Supernovas & Supernova Remnants
Coordinates (J2000)  RA 00h 25m 17s | Dec +64° 08' 37"
Constellation  Cassiopeia
Observation Date  2 pointings between April 29, 2003 and May 3, 2009
Observation Time  283 hours
Obs. ID  3837, 7639, 8551, 10093-10097; 10902-10904; 10906
Instrument  ACIS
Also Known As G120.1+01.4, SN 1572
References Lu, F.J. et al, 2011, ApJ, 732:11
Color Code  Energy: Red 1.6-2.0 keV, Green 2.2-2.6 keV, Blue 4-6 keV
X-ray
Distance Estimate  About 13,000 light years
